Victron SMARTSOLAR MPPT 250/70 VE.Can UP TO 250/100 VE.Can Solar Charge Controller
The Victron SMARTSOLAR MPPT 250/70 to 250/100 VE.Can Solar Charge Controller is an advanced solution for maximising solar energy harvest and ensuring efficient power management for off-grid and hybrid solar systems. Designed for superior performance and durability, this controller is ideal for residential, commercial, and industrial solar instal...
Read MoreThe Victron SMARTSOLAR MPPT 250/70 to 250/100 VE.Can Solar Charge Controller is an advanced solution for maximising solar energy harvest and ensuring efficient power management for off-grid and hybrid solar systems. Designed for superior performance and durability, this controller is ideal for residential, commercial, and industrial solar installations.
Applications:
The SMARTSOLAR MPPT 250/70 to 250/100 VE.Can is perfect for applications requiring reliable and efficient energy management, such as:
Off-grid solar systems
Hybrid solar setups
RVs, boats, and remote installations
Commercial and industrial solar projects
Why Choose the Victron SMARTSOLAR MPPT 250/70 to 250/100 VE.Can?
Combining cutting-edge MPPT technology, robust connectivity options, and user-friendly monitoring features, this solar charge controller offers unparalleled flexibility and reliability. With its exceptional energy efficiency and advanced protection features, it ensures long-term performance, even in demanding conditions.
Features
- Ultra-Fast MPPT Technology: Enhances energy capture by up to 30% compared to PWM controllers, especially under dynamic light conditions.
- Partial Shading Optimisation: Advanced algorithms ensure maximum power point detection for optimal energy harvest even in shaded environments.
- High Conversion Efficiency: With a peak efficiency exceeding 99%, it ensures minimal energy loss during conversion.
- Bluetooth Smart Integration: Easily monitor and configure your charge controller wirelessly via the VictronConnect app.
- VE.Can and VE.Direct Connectivity: Simple integration with GX devices for real-time monitoring and system management.
- Advanced Maximum Power Point Detection in case of partial shading
- Robust Protection: Comprehensive safeguards against PV short circuits, reverse polarity, over-temperature, and more.
- Parallel Charging Capability: Synchronise up to 25 units using VE.Can or 10 units via Bluetooth for larger systems.
- Fully Programmable Charge Algorithms: Customise charging profiles or select from eight pre-configured options for diverse battery types.
- Versatile Application Range: Supports 12V, 24V, and 48V systems with auto-selection, accommodating various solar setups.
Specifications
| SMARTSOLAR CHARGE CONTROLLER | |||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Battery Voltage |
12V, 24V, 36V, 48V Auto Select (software tool needed to select 36V) See selection table |
||||||||||||||||||||||||||||||||||||||||||||||||
| Rated charge current |
See selection table |
||||||||||||||||||||||||||||||||||||||||||||||||
| Nominal PV power |
See selection table |
||||||||||||||||||||||||||||||||||||||||||||||||
| Max PV open circuit voltage |
250V absolute max coldest conditions 245V start-up and operating max |
||||||||||||||||||||||||||||||||||||||||||||||||
| Maximum efficiency |
99% |
||||||||||||||||||||||||||||||||||||||||||||||||
| Self-consumption |
Less than 35mA @ 12V / 20mA @ 48V |
||||||||||||||||||||||||||||||||||||||||||||||||
| Charge voltage 'absorption' |
Default setting: 14,4 / 28,8 / 43,2 / 57,6V (adjustable with: rotary switch, display, VE.Direct or Bluetooth) |
||||||||||||||||||||||||||||||||||||||||||||||||
| Charge voltage 'float' |
Default setting: 13,8 / 27,6 / 41,4 / 55,2V (adjustable with: rotary switch, display, VE.Direct or Bluetooth) |
||||||||||||||||||||||||||||||||||||||||||||||||
| Charge algorithm |
multi-stage adaptive |
||||||||||||||||||||||||||||||||||||||||||||||||
| Temperature compensation |
12V: -16 mV / 24V: -32 mV / 48V: -64 mV/°C |
||||||||||||||||||||||||||||||||||||||||||||||||
| Protection |
Battery reverse polarity (fuse, not user accessible)
PV reverse polarity Output short circuit Over temperature |
||||||||||||||||||||||||||||||||||||||||||||||||
| Operating temperature |
-30 to +60°C (full rated output up to 40°C) |
||||||||||||||||||||||||||||||||||||||||||||||||
| Humidity |
95%, non-condensing |
||||||||||||||||||||||||||||||||||||||||||||||||
| Data communication port |
VE.Direct or Bluetooth |
||||||||||||||||||||||||||||||||||||||||||||||||
| Remote on/off |
Yes (2 pole connector) |
||||||||||||||||||||||||||||||||||||||||||||||||
| Programmable relay |
DPST AC rating: 240VAC / 4A DC rating: 4A up to 35VDC, 1A up to 60VDC |
||||||||||||||||||||||||||||||||||||||||||||||||
| Parallel operation |
Yes (not synchronized) |
||||||||||||||||||||||||||||||||||||||||||||||||
| STANDARDS | |||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Safety | EN/IEC 62109-1, UL 1741, CSA C22.2 | ||||||||||||||||||||||||||||||||||||||||||||||||
| MECHANICAL | |||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Colour | Blue (RAL 5012) | ||||||||||||||||||||||||||||||||||||||||||||||||
| PV terminals |
35 mm² / AWG2 (Tr models) Two sets of MC4 connectors (MC4 models 250/60 and 250/70) . Three sets of MC4 connectors (MC4 models 250/85 and 250/100) . MC4 models: several splitter pairs may be needed to parallel the strings of solar panels. Maximum current per MC4 connector: 30A (the MC4 connectors are parallel connected to one MPPT tracker) |
||||||||||||||||||||||||||||||||||||||||||||||||
| Battery terminals | 35 mm² / AWG2 | ||||||||||||||||||||||||||||||||||||||||||||||||
| Protection category | IP43 (electronic components),
IP22 (connection area) |
||||||||||||||||||||||||||||||||||||||||||||||||
| Weight |
MPPT250/60-70, 3 kg MPPT250/85-100, 4,5 kg |
||||||||||||||||||||||||||||||||||||||||||||||||
|
Dimensions (h.w.d)mm MPPT250/60-70 |
Tr models: 185 x 250 x 95 MC4 models: 215 x 250 x 95 |
||||||||||||||||||||||||||||||||||||||||||||||||
|
Dimensions (h.w.d)mm MPPT250/85-100 |
Tr models: 216 x 295 x 103 MC4 models: 246 x 295 x 103 |
||||||||||||||||||||||||||||||||||||||||||||||||
Selection Table
|
SmartSolar Tr/MC4 Connector |
MPPT 250/70 |
MPPT 250/85 |
MPPT 250/100 |
|---|---|---|---|
|
Battery voltage |
12 / 24 / 48V Auto Select |
12 / 24 / 48V Auto Select |
12 / 24 / 48V Auto Select |
| Rated charge current | 70A | 85A | 100A |
| Nominal PV power, 12V 1a,b) | 1000W | 1200W | 1450W |
| Nominal PV power, 24V 1a,b) | 2000W | 2400W | 2900W |
| Nominal PV power, 48V 1a,b) | 4000W | 4900W | 5800W |
| Max. PV short circuit current 2) | 35A (max 30A per MC4) | 70A (max 30A per MC4) | 70A (max 30A per MC4) |
1a) If more PV power is connected, the controller will limit input power to the stated maximum.
1b) The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V.
2) A PV array with a higher short circuit current may damage the controller in case of reverse polarity connection of the PV array.
