ARIS Power DCU300M3648S DC-UPS / Battery Charger
The DCU300M3648S is a 300W DIN-rail mounted DC-UPS designed to provide uninterrupted power to critical DC loads in industrial and infrastructure applications. It integrates an AC/DC power supply, intelligent battery charger, and backup controller in a single compact unit. The unit accepts a wide input range of 85–305 Vac or 110–420 Vdc and deliv...
Read MoreThe DCU300M3648S is a 300W DIN-rail mounted DC-UPS designed to provide uninterrupted power to critical DC loads in industrial and infrastructure applications. It integrates an AC/DC power supply, intelligent battery charger, and backup controller in a single compact unit.
The unit accepts a wide input range of 85–305 Vac or 110–420 Vdc and delivers a selectable 36 Vdc or 48 Vdc output, making it suitable for a broad range of DC systems.
Designed for high reliability applications, the DCU300M3648S features load-first dynamic power sharing, ensuring priority supply to the load while managing battery charging efficiently. It supports high inrush loads with up to 12 A continuous output and peak currents up to <20 A.
Advanced BattSafe battery management enables optimal battery performance and lifespan, with support for multiple chemistries including lead-acid, AGM, Li-ion, LiFePO₄ and NiCd/NiMH. The charger uses a 3-stage IUoU charging profile with recovery mode and adjustable charge current.
Comprehensive monitoring and control are available via Modbus communication (dual RJ45 ports), alongside local LED diagnostics and three voltage-free relay alarm outputs.
The unit is convection cooled and designed for operation in demanding environments from -25°C to +70°C.
Show Less
Features
- Input voltage range: 85-305Vac nominal operation or 110-420Vdc input.
- Output voltage: Selectable 36Vdc or 48Vdc.
- Output current: Rated 6A at 36Vdc or 5A at 48Vdc in power supply mode.
- Output power: 300W class DC-UPS / battery charger.
- All-in-one DC-UPS with integrated power supply, battery charger and backup functions.
- 3-stage charging curve (IUoU) with recovery charge.
- Adjustable maximum battery charging current.
- Selectable battery types including vented and sealed lead acid, AGM, Li-Ion, Li-PoFe and NiCd/Ni-MH.
- Low voltage disconnect and low voltage alarm thresholds.
- Manual battery start-up button with no mains.
- Battery life test: automatic every 2 hours in standby, or manual on push button.
- Modbus data link via dual RJ45 connector and 3 voltage-free relay contacts for remote alarms.
- Natural convection cooling.
- DIN-rail mounting.
Specifications
| INPUT | |
|---|---|
| Rated Input Voltage | 115/230/277Vac (range 85–305Vac) |
| Rated Input Voltage DC | 110/220Vdc (range 110–420Vdc) |
| Frequency Range | 50/60 Hz (range 47–440Hz) |
| Input Current (Typ.) | 2.8A (115Vac), 1.4A (230Vac) |
| Inrush Current (Typ. Cold Start) | 15A max |
| Setup, Rise Time Max | 1s |
| Recommended External Fuse/MCB | 10A, curve B |
| Load Output - Power Supply Mode (Mains ON & Battery OFF) | ||
|---|---|---|
| Voltage - Selectable by Dip Switch | 36Vdc | 48Vdc |
| Rated Current (IR) | 6A | 5A |
| Ripple / Noise | 80 mVpp | 80 mVpp |
| Short Circuit Protection | Yes | |
| Over Load Protection | Constant Current mode > 110% IR | |
| Over Voltage Protection | 70Vdc | |
| Load Output - Standby Mode (Mains ON & Battery ON) | ||
|---|---|---|
| Voltage Range - Automatic Set | 36–43.2Vdc | 48–57.6Vdc |
| Max Continuous Current (IR+IBATT) | 12A | 10A |
| Max Current for 30s | 15A | 15A |
| Max Current for 15s | 17.5A | 17.5A |
| Max Current for 5s | < 20A | < 20A |
| Load Output - Backup Mode (Mains OFF & Battery ON) | ||
|---|---|---|
| Voltage Range - Automatic Set¹ | 27.7–36Vdc | 37–48Vdc |
| Max Continuous Current (IR+IBATT) | 12A | 10A |
| Max Current for 60s | 15A | 15A |
| Max Current for 30s | 17.5A | 17.5A |
| Max Current for 5s | < 20A | < 20A |
| Time Buffering for Backup | 30 s up to ∞ | |
| Start from Battery with no mains (LVD overide) | Yes (via push button) | |
| Quiescent Current | < 90mA | |
| Signal Output/Input | |
|---|---|
| Standby / Backup | Change-over relay contact, M terminals |
| Common Fault | Change-over relay contact, F terminals |
| Rectifier failure | Change-over relay contact, S terminals |
| Full set of monitor and alarm visual signals | Flashing code on 3, Three-color LEDs |
| Modbus data link | Dual RJ45 connector |
| Climatic Data | |
|---|---|
| Operating Ambient Temperature (TA) | -25 up to +70°C |
| Relative Humidity, no condensation @ 25°C | max 95% |
| Storage Temperature | -40 up to +85°C |
| Cooling | Natural Convection |
| General Data | |
|---|---|
| Efficiency (Typ.) | >91% >91% |
| Temperature Derating Factor¹ | 2.5 %/°C, TA > 50°C |
| Altitude Derating Factor¹ | 0.5°C/100 m, above 2000 m |
| Insulation Voltage (In/Out) | 4 kVac |
| Insulation Voltage (In/PE) | 2 kVac |
| Insulation Voltage (Out/PE) | 500 Vdc |
| Insulation Resistance (500 V) | > 100 MΩ |
| Protection Class (EN/IEC 60529) | IP 20 |
| Pollution Degree Environment | 2 |
| Dimensions (W x H x D) | 80 x 130 x 126 mm |
| Weight | 0.9 kg |
| Commercial Data | |
|---|---|
| Weight per unit, including packing | 1.0 kg |
| Dimensions per unit, including packing | 85 x 138 x 134 mm |
| Volume per unit, including packing | 0.0014 m³ |
| Custom Tarif HS | 85044055 |
| Country of origin | Italy |
| Insulation Voltage (Out/PE) | 500 Vdc |
| Insulation Resistance (500 V) | > 100 MΩ |
| Protection Class (EN/IEC 60529) | IP 20 |
| Pollution Degree Environment | 2 |
| Dimensions (W x H x D) | 80 x 130 x 126 mm |
| Weight | 0.9 kg |
